Powerbox 800 HD SE Wi-Fi

• 10/100MBit compatible Ethernet Interface
• HDMI connector
• plug & play Tuner
• colored OLED display
• plug & play slot for an internal 2,5" SATA hard disk
• additional an eSATA connector

• 400 MHz MIPS Processor
• Enigma 2, Linux Operating System
• colored OLED - Display
• MPEG-2 / H.264 Hardware decoding
• Tuner: DVB-S, optional: DVB-C, DVB-T
• Tuner Module, Plug&Play
• 2 x Smartcard-Reader (Dreamcrypt CA)
• Mini USB for Service and software update
• 10/100Mbit Ethernet Interface
• 1 x Scart (RGB, FBAS or S-Video)
• HDMI
• 2 x USB 2.0
• analog modem
• S/PDIF Interface for digital bit stream out (AC-3)
• 64 MByte Flash, 256 MByte RAM
• 2 x SATA
•  - for internal HDD 2,5“
•  - one external eSATA
• unlimited channel lists for TV/Radio
• channel-change time < 1 second
• automatic service scan
• directly bouquet-lists
• EPG (electronic program guide)
• multiple LNB-Switching control (supports DiSEqC)
• OSD in many languages and skin-support
• Videotext Decoder
• extern 12V power supply

• Frequency Range  950 .... 2150 MHz
• Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
• Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
• DVB-S2: 10 – 31 Mbaud/s (8PSK) , 10 –30 Mbaud/s (QPSK)

• Video Compression MPEG-2 and MPEG-1 compatible, H.246
• Video Formats 4:3 / 16:9
• Letterbox for 4:3 TV-Device

• Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
• Audio Mode Dual (main/sub), Stereo
• Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz

• Output Level L/R 0,5 Vss on 600 Ohm
• THD > 60 dB (1 kHz)
• Crosstalk < -65 dB

• Output Level 0,5 Vss on 75 Ohm
• Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
• S/PDIF-Output optical, Toslink

• Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm

• Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
• Teletext filter in conformity with ETS 300 472 Standard

• Output: FBAS, RGB, S-Video

• Function: Update of Firmware

• 10/100 MBit compatible interface
• Function: Update of Firmware

• analoge modem for Internet connection

• for internal 2,5" HDD and one eSATA

• 2 x USB 2.0 Host

• LNB Current 500mA max.; short-circuit-protected
• LNB Voltage vertical < 14V no load, > 11,5V at 400mA
• LNB Voltage horizontal < 20V no load, > 17,3V at 400mA

• DiSEqC 1.0/1.1/1.2 and USALS (Rotor Control)

• < 15W at 12V

• Input: 110-240V AC / 50-60Hz / 0,6A
• Output: 12V = / 3,0A

• Ambient Temperature +15°C...+35°C
• Humidity < 80%
• Size (W x D x H): 225 mm x 145 mm x 52 mm
• Weight: 940 g  without HDD
